| Part Number | Vrwm(V) | Vbr min.(V) | It(mA) | Vc(V) | Ipp(A) | Ir(μA) |
| 15KPA17A 15KPA17CA | 17.0 | 18.99 | 50 | 29.3 | 515.4 | 5000 |
| 15KPA18A 15KPA18CA | 18.0 | 20.11 | 50 | 30.9 | 488.7 | 5000 |
| 15KPA20A 15KPA20CA | 20.0 | 22.34 | 20 | 34.3 | 440.2 | 1500 |
| 15KPA22A 15KPA22CA | 22.0 | 24.57 | 10 | 37.1 | 407.0 | 500 |
| 15KPA24A 15KPA24CA | 24.0 | 26.81 | 5 | 40.7 | 371.0 | 150 |
| 15KPA26A 15KPA26CA | 26.0 | 29.04 | 5 | 44.0 | 343.2 | 50 |
| 15KPA28A 15KPA28CA | 28.0 | 31.28 | 5 | 47.5 | 317.9 | 25 |
| 15KPA30A 15KPA30CA | 30.0 | 33.51 | 5 | 50.7 | 297.8 | 15 |
| 15KPA33A 15KPA33CA | 33.0 | 36.90 | 5 | 54.7 | 276.1 | 2 |
| 15KPA36A 15KPA36CA | 36.0 | 40.20 | 5 | 59.8 | 252.5 | 2 |
| 15KPA40A 15KPA40CA | 40.0 | 44.70 | 5 | 65.8 | 229.5 | 2 |
| 15KPA43A 15KPA43CA | 43.0 | 48.00 | 5 | 69.8 | 216.3 | 2 |
| 15KPA45A 15KPA45CA | 45.0 | 50.30 | 5 | 72.8 | 207.4 | 2 |
| 15KPA48A 15KPA48CA | 48.0 | 53.60 | 5 | 77.7 | 194.3 | 2 |
| 15KPA51A 15KPA51CA | 51.0 | 57.00 | 5 | 82.9 | 182.1 | 2 |
| 15KPA54A 15KPA54CA | 54.0 | 60.30 | 5 | 87.7 | 172.2 | 2 |
| 15KPA58A 15KPA58CA | 58.0 | 64.80 | 5 | 93.8 | 161.0 | 2 |
| 15KPA60A 15KPA60CA | 60.0 | 67.00 | 5 | 97.4 | 155.0 | 2 |
| 15KPA64A 15KPA64CA | 64.0 | 71.50 | 5 | 104.2 | 144.9 | 2 |
| 15KPA70A 15KPA70CA | 70.0 | 78.20 | 5 | 113.6 | 132.9 | 2 |
| 15KPA75A 15KPA75CA | 75.0 | 83.80 | 5 | 122.0 | 123.8 | 2 |
| 15KPA78A 15KPA78CA | 78.0 | 87.10 | 5 | 126.1 | 119.7 | 2 |
| 15KPA85A 15KPA85CA | 85.0 | 94.90 | 5 | 137.6 | 109.7 | 2 |
| 15KPA90A 15KPA90CA | 90.0 | 100.50 | 5 | 145.6 | 103.7 | 2 |
| 15KPA100A 15KPA100CA | 100.0 | 111.70 | 5 | 161.3 | 93.6 | 2 |
| 15KPA110A 15KPA110CA | 110.0 | 122.90 | 5 | 178.6 | 84.5 | 2 |
| 15KPA120A 15KPA120CA | 120.0 | 134.00 | 5 | 192.3 | 78.5 | 2 |
| 15KPA130A 15KPA130CA | 130.0 | 145.20 | 5 | 208.3 | 72.5 | 2 |
| 15KPA150A 15KPA150CA | 150.0 | 167.60 | 5 | 241.9 | 62.4 | 2 |
| 15KPA160A 15KPA160CA | 160.0 | 178.70 | 5 | 258.6 | 58.4 | 2 |
| 15KPA170A 15KPA170CA | 170.0 | 189.90 | 5 | 272.7 | 55.4 | 2 |
| 15KPA180A 15KPA180CA | 180.0 | 201.10 | 5 | 288.5 | 52.3 | 2 |
| 15KPA200A 15KPA200CA | 200.0 | 223.40 | 5 | 319.1 | 47.3 | 2 |
| 15KPA220A 15KPA220CA | 220.0 | 245.70 | 5 | 352.5 | 42.8 | 2 |
| 15KPA240A 15KPA240CA | 240.0 | 268.10 | 5 | 384.6 | 39.3 | 2 |
| 15KPA260A 15KPA260CA | 260.0 | 290.40 | 5 | 416.7 | 36.2 | 2 |
| 15KPA280A 15KPA280CA | 280.0 | 312.80 | 5 | 454.5 | 33.2 | 2 |
