| Part Number | Vrwm(V) | Vbr min.(V) | It(mA) | Vc(V) | Ipp(A) | Ir(μA) |
| 20KPA20A 20KPA20CA | 20.0 | 22.34 | 50 | 36.8 | 548.9 | 5000 |
| 20KPA24A 20KPA24CA | 24.0 | 26.81 | 50 | 41.2 | 490.3 | 5000 |
| 20KPA26A 20KPA26CA | 26.0 | 29.04 | 50 | 44.7 | 451.9 | 2000 |
| 20KPA28A 20KPA28CA | 28.0 | 31.28 | 50 | 48.0 | 420.8 | 1000 |
| 20KPA30A 20KPA30CA | 30.0 | 33.51 | 5 | 51.5 | 392.2 | 250 |
| 20KPA32A 20KPA32CA | 32.0 | 35.74 | 5 | 54.3 | 372.0 | 150 |
| 20KPA34A 20KPA34CA | 34.0 | 38.00 | 5 | 57.5 | 351.3 | 50 |
| 20KPA36A 20KPA36CA | 36.0 | 40.20 | 5 | 61.5 | 328.5 | 20 |
| 20KPA40A 20KPA40CA | 40.0 | 44.70 | 5 | 67.8 | 297.9 | 15 |
| 20KPA44A 20KPA44CA | 44.0 | 49.10 | 5 | 72.7 | 277.9 | 2 |
| 20KPA48A 20KPA48CA | 48.0 | 53.60 | 5 | 79.4 | 254.4 | 2 |
| 20KPA52A 20KPA52CA | 52.0 | 58.10 | 5 | 85.8 | 235.4 | 2 |
| 20KPA56A 20KPA56CA | 56.0 | 62.60 | 5 | 92.6 | 218.1 | 2 |
| 20KPA60A 20KPA60CA | 60.0 | 67.00 | 5 | 97.6 | 207.0 | 2 |
| 20KPA64A 20KPA64CA | 64.0 | 71.50 | 5 | 104.0 | 194.2 | 2 |
| 20KPA68A 20KPA68CA | 68.0 | 76.00 | 5 | 110.0 | 183.6 | 2 |
| 20KPA72A 20KPA72CA | 72.0 | 80.40 | 5 | 116.0 | 174.1 | 2 |
| 20KPA80A 20KPA80CA | 80.0 | 89.40 | 5 | 130.0 | 155.4 | 2 |
| 20KPA88A 20KPA88CA | 88.0 | 98.30 | 5 | 142.0 | 142.3 | 2 |
| 20KPA96A 20KPA96CA | 96.0 | 107.20 | 5 | 155.0 | 130.3 | 2 |
| 20KPA104A 20KPA104CA | 104.0 | 116.20 | 5 | 168.0 | 120.2 | 2 |
| 20KPA112A 20KPA112CA | 112.0 | 125.10 | 5 | 182.0 | 111.0 | 2 |
| 20KPA120A 20KPA120CA | 120.0 | 134.00 | 5 | 194.0 | 104.1 | 2 |
| 20KPA132A 20KPA132CA | 132.0 | 147.40 | 5 | 213.0 | 94.8 | 2 |
| 20KPA144A 20KPA144CA | 144.0 | 160.80 | 5 | 232.0 | 87.1 | 2 |
| 20KPA160A 20KPA160CA | 160.0 | 178.70 | 5 | 258.0 | 78.3 | 2 |
| 20KPA172A 20KPA172CA | 172.0 | 192.10 | 5 | 277.0 | 72.9 | 2 |
| 20KPA180A 20KPA180CA | 180.0 | 201.10 | 5 | 291.0 | 69.4 | 2 |
| 20KPA192A 20KPA192CA | 192.0 | 214.50 | 5 | 309.0 | 65.4 | 2 |
| 20KPA204A 20KPA204CA | 204.0 | 227.90 | 5 | 329.0 | 61.4 | 2 |
| 20KPA216A 20KPA216CA | 216.0 | 241.30 | 5 | 348.0 | 58.0 | 2 |
| 20KPA232A 20KPA232CA | 232.0 | 259.10 | 5 | 374.0 | 54.0 | 2 |
| 20KPA240A 20KPA240CA | 240.0 | 268.10 | 5 | 387.0 | 52.2 | 2 |
| 20KPA256A 20KPA256CA | 256.0 | 286.00 | 5 | 412.0 | 49.0 | 2 |
| 20KPA280A 20KPA280CA | 280.0 | 312.80 | 5 | 451.0 | 44.8 | 2 |
| 20KPA300A 20KPA300CA | 300.0 | 335.10 | 5 | 483.0 | 41.8 | 2 |
